Included Parts

- a: Backrest

- b: Seat Cushion

- c: Armrests (Left & Right)

- d: Headrest

- e: Pallet (Tilt Mechanism)

- f: Five-star Base

- g: Wheels (5 pcs)

- h: Gas Lift (Air Rod)

- i: Hex Wrench

- j: Screws (M6×16mm, 4 pcs)

- k: Screws (M6×30mm, 10 pcs)

Tools Required

• Hex Wrench (included)

• No additional tools are required.

Assembly Steps

1. Insert the 5 wheels (g) into the five-star base (f). Insert the gas lift (h) into the center of the base.

2. Flip the seat cushion (b) upside down. Attach the armrests (c) and tilt mechanism (e) to the seat using screws j (M6×16mm) and k (M6×30mm) as shown.

3. Attach the backrest (a) to the seat from the rear side using screws k. Then connect the entire top assembly onto the gas lift.

4. Finally, attach the headrest (d) to the top of the backrest using remaining screws k. Your chair is now assembled and ready for use.
